Wichard D Self Locking Shackle
Wichard D Self Locking Shackles are made from 316L marine grade stainless steel with a high polished finish. At the thumb screw end the elasticity of the shackle's body locks the pin's position into small indentation preventing any accidental release due to vibration. Suitable for highly corrosive environments Wichard D Self Locking Shackles are very well known in marine industry.Â
| Part No. | Pin Dia.(mm) | A (mm) | B (mm) | Work (kg) | Break (kg) |
|---|---|---|---|---|---|
| WD-1201 | 4 | 13 | 8 | 320 | 700 |
| WD-1202 | 5 | 16 | 10 | 400 | 1000 |
| WD-1203 | 6 | 20 | 12 | 600 | 1600 |
| WD-1204 | 8 | 26 | 16 | 1000 | 2700 |
| WD-1205 | 10 | 33 | 20 | 1520 | 4300 |
| WD-1206 | 12 | 39 | 24 | 2080 | 6000 |
Original: $7.74
-65%$7.74
$2.71Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Wichard D Self Locking Shackles are made from 316L marine grade stainless steel with a high polished finish. At the thumb screw end the elasticity of the shackle's body locks the pin's position into small indentation preventing any accidental release due to vibration. Suitable for highly corrosive environments Wichard D Self Locking Shackles are very well known in marine industry.Â
| Part No. | Pin Dia.(mm) | A (mm) | B (mm) | Work (kg) | Break (kg) |
|---|---|---|---|---|---|
| WD-1201 | 4 | 13 | 8 | 320 | 700 |
| WD-1202 | 5 | 16 | 10 | 400 | 1000 |
| WD-1203 | 6 | 20 | 12 | 600 | 1600 |
| WD-1204 | 8 | 26 | 16 | 1000 | 2700 |
| WD-1205 | 10 | 33 | 20 | 1520 | 4300 |
| WD-1206 | 12 | 39 | 24 | 2080 | 6000 |
