Yamaha 2.5hp Outboard Engine

Compact and reliable, the Yamaha 2.5hp outboard engine delivers dependable performance for small boats and dinghies. This lightweight motor features fuel-efficient operation, making it ideal for leisurely cruising and fishing trips. Built with Yamaha's trusted engineering, it offers smooth acceleration and easy handling. Perfect for boaters seeking a practical, low-maintenance solution that won't compromise on quality or durability.

• BMHS - Short shaft (15") - 17kg
• BMHL - Long shaft (20") - 18kg

  • Engine type: OHV, 1-cylinder
  • Displacement: 72 cm³
  • Bore x stroke: 54.0 × 31.5 mm
  • Compression ratio: 8.8 : 1
  • Fuel induction system: 1 carburetor
  • Lubrication system: Splash lubrication
  • Engine oil capacity: 0.25 L
  • Ignition / advance system: CDI
  • Alternator: Not available



  • Overall length: 625 mm
  • Overall width: 363 mm
  • Overall height: S: 1028 mm, L: 1155 mm
  • Engine transom height: S: 433 mm, L: 560 mm
  • Steering angle: 360 degree full pivot
  • Dry weight: S: 17kg, L: 18 kg



  • Maximum propeller shaft output: 1.8 kW
  • Full throttle operating range: 5250 – 5750 r/min
  • Idling speed: 1800 – 2000 r/min



  • Shallow water drive: Not available
  • Gear shift: F-N
  • Gear ratio: 2.08 (27/13)
  • Gear oil capacity: 0.075 L
