Yamaha 6hp Outboard

The Yamaha 6hp Outboard delivers reliable performance for small boats and dinghies. This compact, lightweight engine features fuel-efficient operation and easy starting, making it ideal for recreational boating and fishing trips. Built with Yamaha's trusted engineering, it offers smooth acceleration and dependable power in a portable package. Perfect for navigating shallow waters and tight spaces, this outboard combines durability with low maintenance requirements. Whether you're exploring coastal areas or enjoying quiet days on the water, this versatile motor provides the efficiency and control you need.

A built-in fuel tank keeps the deck clear, while Yamaha's clever three-position storage system means no messy oil leaks (or the associated in-car arguments) when you pack it away. The carry handle's robust, the start-up's effortless and the whole design whispers "refinement", right before it growls into action...

Whether you're cruising the coastline, exploring quiet inlets or keeping it handy as an auxiliary, the 6hp is always game for adventure. Reliable, economical and effortlessly stylish; it's Yamaha freedom, with a little extra muscle.

Engine type	OHV, 1-cylinder
Displacement	139 cm³
Bore x stroke	62.0 × 46.0 mm
Compression ratio	8.9 : 1
Fuel induction system	1 carburetor
Lubrication system	Wet sump
Engine oil capacity	0.6 L
Ignition / advance system	CDI
Alternator	6 A with optional regulator

Overall length	750 mm
Overall width	403 mm
Overall height	S: 1039 mm, L: 1166 mm
Engine transom height	S: 435 mm, L: 562 mm
Steering angle	90 degrees each direction
Dry weight	S: 27 kg, L: 28 kg

Maximum propeller shaft output	4.4 kW
Full throttle operating range	4500 – 5500 r/min
Idling speed	1450 – 1550 r/min

Shallow water drive	3 positions
Gear shift	F-N-R
Gear ratio	2.08 (27/13)
Gear oil capacity	0.100 L
